Pipeline Repair patch for joint Coating damage
-
$10.00≥500 Square Meter
- Min. Order:
- 500 Square Meter
- Min. Order:
- 500 Square Meter
- Transportation:
- Ocean, Land
- Port:
- Shenzhen, Shanghai , Qingdao
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 500 sqm/day |
| Supply Ability: | 5000 rolls/Month |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF,EXW |
| Certificate: | ISO |
| HS Code: | 3919 |
| Transportation: | Ocean,Land |
| Port: | Shenzhen, Shanghai ,Qingdao |
Pipeline repair patch for pipeline damage
Repair for 3PE coating damage
Repair Patch is designed for repair of damaged PE-coating on steel pipe and the amendment of the holes or crack which the diameter smaller than 100mm on the backing layer of Heat Shrinkable Tape/Sleeve. If damage area of coating pipeline greater than 100mm.Heat Shrinkable Wraparound Sleeve (or Heat Shrinkable Wraparound Tape) is recommended .
Product
Width(㎜) × Length(㎜)Roll
Note
Repair Tape
100×100
Product can be cut in needed size for the hole
Repair Tape
150×150
Product can be cut in needed size for the hole
Repair Tape
250×250
Product can be cut in needed size for the hole
Repair Tape
300×300
Product can be cut in needed size for the hole
Repair Tape
250×450
Product can be cut in needed size for the hole
Thickness
Base material
0.8mm
Adhesive
1.2mm
Repair Patch is designed for repair of damaged PE-coating on steel pipe and the amendment of the holes or crack which the diameter smaller than 100mm on the backing layer of Heat Shrinkable Tape/Sleeve. If damage area of coating pipeline greater than 100mm. Heat Shrinkable Wraparound Sleeve (or Heat Shrinkable Wraparound Tape) is recommended .
Features & Benefits
Repair patch consists of an irradiated, cross-linked polyolefin sheet coated with a heat activated adhesive.
Mainline coating repair products including melt stickers and repair patches compatible with common pipeline coatings.
Both the sticker and patch can be installed quickly with no special tools required.
The installed patch provides a barrier to moisture and corrosion and is resistant to abrasion and shear forces during pipeline installation and while in-service.
