Anti UV Textured Polyester Film For Membrane Switch

    Item No: Anti UV XE F150     Width: 610mm, 1220mm    Regular Roll Length:100meters

General description

JP XE F150 PET FILM is a high quality, embossable, fine velvet surface textured hard coated polyester film, a long life film for devices of our door . Film supplied as sheets or rolls, with or without protective films.

The coating significantly enhances the chemical resistance and the flex life of the base film thus extending the functionality of polyester film into areas demanding high abrasion resistance together with excellent receptivity to graphic inks. Film is optimised for a range of applications requiring a combination of high abrasion resistance and flexibility.

ANTI UV  CHART OF JP XE F150

Versions using special heat stabilized polyester film with a typical residual shrinkage of < 0.3% @ 150°C are also available for demanding applications.

Advantage of PET Film

1,Excellent performances of friction resistance, scratch resistance and chemical resistance.

2, Long lifespan and bending resistance

3,Good thermostability, easy to print , free of overdrying while processed with multicolors.

4, With window liquid easy open clear window .

5, Suitable for both UV ink and Solvent ink, screen printing suggested.

   For anti uv PET film, we designed different surface textures for market, including glossy surface anti uv, AG surface anti uv, fine velvet and velvet textured surface anti uv.

Main Features

·         Excellent scratch resistance 2H~3H

·         Multiple Textures and haze levels available including Gloss, Anti-glare and  Matte (Fine and Velvet)

·         Receptive to a range of UV and solvent based varnishes

·         Embossable       ·         Resistant to wide range of chemicals

·         Very high optical clarity         ·         Exceptional flex life

Applications

JP FILM is optimised for the following out door devices applications

- Membrane  switches     Fascia panels     Touch panels    Nameplates  Label & Tags
