FEP 3D Printed Release Film for DLP Photocuring

FEP 3D Printed Release Film for DLP Photocuring

$130.00

≥100 Kilogram

Min. Order:: 100 Kilogram

Min. Order:: 100 Kilogram

Transportation:: Ocean, Land, Air

Port:: Shanghai, Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Supply Ability:	5 ton per month
Payment Type:	L/C,T/T,D/P,Paypal
Incoterm:	FOB,CFR,CIF,EXW,FCA,CPT,CIP
Certificate:	ISO
HS Code:	39209990
Transportation:	Ocean,Land,Air
Port:	Shanghai,Shenzhen

Product Description

FEP 3D Printing Release Film 0.1 0.15 0.2mm

3D Printed Release Film FEP Special for DLP Photocuring

FEP fluoroplastic film has perfect properties of non-stick, temperature resistance,dielectric,mechanical,abrasive resistance etc. It is suitable for 3D printing(UV curable) releasing . FEP film has perfect releasing force,it can meets kinds of proucts' releasing requirements .High transmission of light let UV light can penetrate fully ,making the printed products more beautiful and improve products quality .

FEP releasing film properties :

Release force--good peeling performance,can be reused

High transmission of light-- above 95%

Anticorrosion--not effected by any Strong acids, bases, oxidizers and almost all solvents.

non-stick--smooth surface making better release property and durability

temperature resistance--working temperature -190oC to 240oC

Fireproof--UL94 V0 grade

Application :

special for DLP SLA 3D Printer UV curable releasing

FEP 3D Releasing Film

Specification :

Thickness	width	length	remar
150um	1250mm	100-500m	thickness ,width,length can be customised
180um	1250mm	100-500m	thickness ,width,length can be customised

Item	Thickness(mm)	Thickness Tolerance	Width(mm)
FEP film	0.05	0~+0.01	10-300
	0.07
	0.08
	0.09
	0.10
	0.15

3D printer membrane sheet form

Our 3D printer membrane is our newest products for 3D printer releasing specially .It is used for 3D printers

which (UV curing,SLA and DLP type).It is placed in a tray for the glue to release, instead of silicone film

Main features:

1. high transmittance, UV light through rate of 92%, the curing time is shorter, better curing effect, higher

precision printing;

2. More durable, release more than ten thousands times. (refer to the printed page);

3. For many types of UV light curing 3D printer.

Type A: It can both directly to put the film into the tray , and can tear out the protective film out and paste the

release film onto the tray .It is more convenient than using a silicone membrane,and the using life is far more

than silicon film. The using method is like pasting mobile protective film.

Type B without adhesive ,but it need to be fixed at the bottom of the tray .

Size: 210 * 290 mm, and about the same size A4 paper, special sizes (20 or more) contact the owner

customization.

Thickness: A 0.125 mm; B, 0.1 mm.

Note: A paragraph has positive and negative film, after which goes without adhesive protective film, the protective film is peeled off the adhesive tape stuck on that side glue tank; B section is no positive and negative, can be used on both sides.(Product development phase is currently in trial, is currently testing a small scale

trial, so a limited number of sales.)

HOW TO USE IT ?

Cutting :

Please choose a clean ,windless,dustfree room to operate. Washing hands clean,using art knife to cut the film into the right size you need .Edge must be orderly.Size can be a little smaller than the glue tank’s bottom plane.

Clean:

Clean the glue tank with microfiber cleaning cloth which is sent with the goods （or other glasses

cloth),no Dust or blot,or it will comes our bubble after pasting.

Paste:

Tear up the protective film from the 3D printer film at one corner and then paste it like pasting a

phone’s protecting film .
