0.25-0.5mm FEP Tape-Casting Anticorrosive Dielectric Film

0.25-0.5mm FEP Tape-Casting Anticorrosive Dielectric Film

$115.00

≥100 Kilogram

Min. Order:: 100 Kilogram

Min. Order:: 100 Kilogram

Transportation:: Ocean, Land, Air, Express, Others

Port:: Shanghai, Shenzhen

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Supply Ability:	5 ton per month
Payment Type:	L/C,T/T,D/P,Paypal
Incoterm:	FOB,CFR,CIF,EXW,FCA,CPT,CIP
HS Code:	3920999090
Transportation:	Ocean,Land,Air,Express,Others
Port:	Shanghai,Shenzhen

Product Description

0.25-0.5mm FEP Tape-Casting Anticorrosive Dielectric Film Made in China

0.0125-0.5mm x Max 1200mm
Perfect tolerance +-0.005mm
Perfect tensile strength

FEP not only has similar properties to ptFE, but also has good machining properties of thermoplastic. Therefore, it makes up for the shortage of the processing difficulty of ptFE, making it a substitute material for PTFE. FEP has excellent heat resistance, low friction, non-viscosity and lubricity, chemical resistance, thermal stability and electrical insulation. FEP is widely used in electrical, electronic, chemical, aviation, machinery and other industrial sectors, as well as rocket, missile, aerospace and other advanced science and technology and national defense industry sectors.

FEP films are used as seals for capacitors, diaphragms, chemical equipment, printing plates and flexible cables in the printing industry. The film can be welded, can be vacuum processed, can be coated with metal, the surface does not need to be activated, under heat and pressure can be bonded with metal and glass cloth.

FEP films are particularly resistant to gas permeability and are therefore used as sensing elements for gas analyzers and as diaphragms isolated from the analyzed gas.
FEP mould blowing film

0.0125-0.5mm x 300mm width
0.05-0.15mm x 1000mm width

FEP colorful film red black yellow orange blue

0.0125-0.5mm x 300mm MOQ 50kgs

Application :

* Agglutinant
* electric iron board producing
* F4 wax cloth belt, transmission belt combining adhibiting
* F4 copper board inner adhibiting
* Window
* Electroanalysis
* High temperature tape raw material
* Capacitance raw material
* Biology temperature protecting material
* Non-metal compensator in thermo-eletric plant
* Flameproof electric machinery

* Surface protecting material

Properties :

High low temperature resistance:

-200--200°C,high temperature strength is 2 times higher than PTFE
Good adhesive and heat sealability with PTFE:

Below melting point ,it won’t stick any project.Above melting point, it has perfect adhesive property with PTFE, Metal and self-adhesion(heat sealing).

None stick to water ,oil : water contact angle: θ=115o
Electric reliability,High dielectric
60HZ-60MHZ , Under the high and low temperature,the permittivity keeps 2.1 even if the surface

damaged ,it won’t has conductive track.

Volume resistance>1018ΩM
Surface resistance>2*1013Ω
Voltaic Arc Resistance >165s No electric leakage
Weather resistance: It can be used in sunlight and ozone long
Anti-corrosion :Only in high temperature, Fluorin and alkalis can effect it,others acid, alkali or ester
