12000lbs 4x4 wire rope Car Electric Winch
  • 12000lbs 4x4 wire rope Car Electric Winch
12000lbs 4x4 wire rope Car Electric Winch

12000lbs 4x4 wire rope Car Electric Winch

  • USD200
    ≥1 Set/Sets
Payment Type:
T/T, Paypal, Money Gram, Western Union
Incoterm:
FOB, CFR, CIF, EXW, FCA, CPT, CIP
Min. Order:
1 Set/Sets
Min. Order:
1 Set/Sets
Delivery Time:
2 Days
Transportation:
Ocean, Air
Port:
NINGBO
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: CHINA
Productivity: 50000SETS/YEAR
Supply Ability: 50000SETS/YEAR
Payment Type: T/T,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW,FCA,CPT,CIP
Certificate: CE
HS Code: 8425319000
Transportation: Ocean,Air
Port: NINGBO
Product Description
Product Description

This is 12000lbs auto winch can be with nylon rope and wire rope. you can choose 12V, 24V.

we can do OEM.

12000lbs Winch 2

SPECIFICATIONS
Rated Line Pull 12000LB (5443kgs) single line
Motor 6.6hp/4.8kw(12V) 4.0hp/3.0kw(24V) Series Wound
Control Remote switch, 12ft(3.7m)lead
Gear train 3 Stage Planetary
Gear train ratio 187.2:1
Clutch Sliding Ring Gear
Braking Action Automatic In-The-Drum
Drum Size Diameter 2.52"(64mm)Length 8.82"(224mm)
Cable 23/64" of 94ft dianeter (Φ9.1mm*28m)
Fairlead 4-Way Roller Fairlead
Remote Control Optional
Battery Recommended:650CCA minimum for winching
Battery Leads 2 gauge,72"(183mm)
Finish Dark gray powder coat
Overall Dimensions 21.1"×6.3"×8.6"(537mm×160mm×218mm)
Mounting Bolt Pattern 254mm×114.3mm
Weight N.W.40kg    G.W.42kg
Packing Size 57×19×34.5cm    1PC/CTN

12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 12V
Line Pull
lbs
0
4000
6000
8000 10000 12000
kg
0 1810 2720 3630 4540 5440
Line Speed
ft/min
33.3 16.8 12.8 10.1 8.8 7.6
m/min
10.3 5.1 3.9 3.1 2.7 2.3
Motor
Amps
85 158 231 302 371 450

12000LB LINE SPEED AND AMP DRAW (FIRST LAYER) 24V
Line Pull
lbs
0
4000
6000
8000 10000 12000
kg
0 1810 2720 3630 4540 5440
Line Speed
ft/min
35 18.5 14.4 11.5 10 8.9
m/min
10.8 5.6 4.4 3.5 3.1 2.7
Motor
Amps
50 136 170 210 240 280

12000LB LINE PULL AND CABLE CAPACITY
Layers of cable 1 2 3 4
Rated line pull per layer lbs 12000 9210 8030 6894
kg 5443 4170 3640 3125
Cumulative cable capacity ft 17 41 71 82
m 4.8 12 21 25
