fused Wavelength Division Multiplexer

Specifications Applications

EDFA modules

WDM systems

Opical device

  Specifications

Parameters	Unit	Values
Operating wavelength	nm	1310&1490
Operating bandwidth	nm	±10
Insertion loss	dB	<0.45
Isolation	dB	>15
PDL	dB	<0.15
Directivity	dB	≥45
Operating temperature	°C	0 ~ +70
Configuration	--	1*2 or 2*2
Fiber Type	--	SMF-28E
Fiber Length	m	1.0 or others

  *For devices with connectors, IL will be 0.3dB higher and RL will be 5dB lower.         Ordering Information JZWDM-1-2-3-4

1 Wavelength	2 Port	3 Connector	4 Package
1-980/1550 2-980/1590 3-1310/1550 4-1310/1490	1-1x2 2-2x2	1-FC/APC 2-FC/UPC 3-SC/APC 4-SC/UPC 5-LC/UPC 6-LC/APC N-none S-specify	1-3.0*48 2-ABS 3.others
