polarization insentive passive fiber optic circulator module C band L band

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Sichuan, China (Mainland)

Product Description

Specifications Applications

Fiber Optic Instruments

DWDM System

C+L Band Polarization Insensitive Mini Fiber Optic Circulator Specifications

Parameters	Unit	Values
Center Wavelength		1525~1610
Typ. Insertion Loss with Connector	dB	0.9
Max. Insertion Loss with Connector	dB	1.3
Min. Isolation @ Operation Temperature &Operating Wavelength	dB	35
Max. Polarization Dependent Loss	dB	0.2
Max. Polarization Mode Dispersion	dB	0.1
Min. Cross Talk	dB	50
Min. Return Loss	dB	50
Max. Optical Power (CW)	mW	500
Max. Tensile Load	N	5
Fiber Type		SMF-28 fiber
Operating Temperature	°C	-5 to +50
Storage Temperature	°C	-40 to +85

*IL is 0.3 dB higher and RL is 5 dB lower for each connector added
